Pallet Cage for Shipping Vessel

Scope

3T Pallet Cage for shipping vessel

Requirements

The following requirements were noted prior to the design of the Pallet Cage:

– A lifting capacity of 3,000kg was required

– The cage had to be capable of containing two standard size pallets side by side

– The cage had to be capable of being transported by a variety of different means.

– The cage had to have an enclosed roof to prevent damage to cargo due to falling objects.

Solution

The solution provided was an 3,000kg Pallet Cage complete with:

– 2 No. Lockable doors with spring loaded locking pins.

– Weld mesh wall sections to prevent any cargo from falling free.

– Lifting Lugs on top of the cage to allow it to be loaded and unloaded from a ship using a dockside crane.

– Fork Pockets to allow it be transported using a standard fork truck

– 4 No. All swivel all brake castors for movement using a single operator.

– Increased Roof struts to prevent any crush damage should cargo fall on top of the cage.
